ICON iKeyboard 6X 61 Semi Weighted Keys Keyboard
ICON iKeyboard 6X 61 Semi Weighted Keys Keyboard
ICON iKeyboard 6X 61 Semi Weighted Keys Keyboard
ICON iKeyboard 6X 61 Semi Weighted Keys Keyboard
, ,

ICON iKeyboard 6X 61-Keys Semi Weighted Keys Keyboard

ICON
Availability:

Out of stock

SKU: IKEYBOARD6X

The X Series iKeyboard 8X MIDI Contoller from ICON combines an 61-key piano keyboard with a single channel DAW controller in a rugged metal enclosure. The controller features pitch bend and modulation wheels, and Octave and Transpose up/down buttons.

Key Features

  •  61 semi-weighted keys
  •  24-Bit 96/192KHz 2-In/2-Out USB Recording Interface
  • 2×2 analog I/O full duplex recording and playback
  •  1 mic input with individual gain control
  • 2 analog inputs and 2 analog outputs on 1/4” TRS jack

Call for Price

ICON iKeyboard 6X 61-Keys Semi Weighted Keys Keyboard

The ICON iKeyboard 6X 61 Semi Weighted Keys Keyboard is a powerful MIDI keyboard controller equipped with a high quality 24-bit 96/192khz 2-In/2-Out USB audio interface, Mackie Control and HUI protocol to control your DAW software. The flexible, functional and effortless setup lets you get right down to business.

FEATURES:

● 61 semi-weighted keys
● 24-Bit 96/192KHz 2-In/2-Out USB Recording Interface
● 2×2 analog I/O full duplex recording and playback
● 1 mic input with individual gain control
● 2 analog inputs and 2 analog outputs on 1/4” TRS jacks
● Backlit LED touch fader reacts in real-time with DAW.
● Synchronize automatically with different channel values when switching between channels
● Dual function encoder knob (Enter & rotate)
● 11-segment LED surrounding the encoder to indicate the rotating position
● Velocity-sensitive piano style keyboard
● Modulation and Pitch jog-wheel
● 3-segment LED screen
● 18 assignable LED backlit buttons
● Illuminated channel buttons including Rec-enable, Solo and Mute
● 6 illuminated transport buttons including Play, Stop, Rec, Rewind, Fast Forward and Loop
● Transpose button with key switch for quick and easy pitch shift.
● Octave up/down buttons
● Multi velocity curves available for selection (Key and Pads)
● Midi output jack
● 1 headphone output with assignable source and individual volume control
● Expression & sustain pedal TRS connectors
● Flexible channel routing via the software control panel
● Supports DirectSound, WDM and ASIO2.0
● Full duplex, simultaneous record/playback
● Mackie control built-in for Cubase, Nuendo, Samplitude, Logic Pro, Bitwig, Reason, Reaper, Studio One and Abelton Live
● Mackie HUI protocol built-in for Pro Tools
● Driver built-in for Cubase, Nuendo, Bitwig and Reason for plug and play
● iMapTM software included for easy mapping of MIDI functions
● Firmware upgrades available via USB connection and iMap software
● Compatible with Mac OS (Intel-Mac) and Windows XP, Vista (32-bit/64-bit), Windows 7 (32-bit/64-bit) & Windows 8 (32-bit/64-bit)
● USB 2.0 high speed connectivity
● Robust metal casing with Kensington lock port

View details on manufacturer’s website

SKU: IKEYBOARD6X Categories: , , Tags: , , , , , , , , ,

ICON iKeyboard 6X Specs

Weight 10.7 lbs
Dimensions 40.51 × 7.44 × 2.48 in
Brands

Specifications

Connector
USB USB connector (standard type)
Sustain & Expression 2×1/4” TS connectors
MIDI I/O 5-pin Din connector
Line in (L/R) 2×1/4” TS connectors
Line Out (L/R) 2×1/4” TS connectors
Mic in XLR balanced connector
Headphone out 1/4” stereo connector
General
Power supply 7V/1A DC
Current consumption 500mA or less
Weight 4.85kg 10.7(lb)
Dimensions 1029(L)x189(W)x63(H)mm
Dimensions 40.51″(L)x7.44″(W)x2.48″(H)
Mic Input (at Minimum Gain)
Frequency Response 22Hz to 22kHz (+/-0.1dB
Dynamic Range 93dB, A-weighted
Signal-to-Noise Ratio -93dB, A-weighted
THD+N <0.0061% (-90dB)
Crosstalk -87dB @ 1kHz
Input Impedance Mic in: 1.8K Ohms, typical
Adjustable Gain +34dB
Total Gain Range +50dB
Line Inputs 1/2 (Unbanced)
Frequency Response 22Hz to 22kHz (+/-0.1dB
Dynamic Range 100dB, A-weighted
Signal-to-Noise Ratio -100dB, A-weighted
THD+N <0.0061% (-90dB)
Crosstalk -100dB @ 1kHz
Nominal Input Level Unbalanced: +4dBV, typical;
Maximum Input level Unbalanced: +11dBV, typical;
Input Impedance 10K Ohms, typical
Line Outputs 1/2 (Unbanced)
Frequency Response 22Hz to 22kHz (+/-0.1dB
Dynamic Range 102dB, A-weighted
Signal-to-Noise Ratio -102dB, A-weighted
THD+N <0.003% (-90 dB)
Crosstalk -100dB @ 1kHz
Nominal Output Leve Unbalanced: +4dBV, typical;
Maximum Output Level +11dBV, typical;
Output Impedance 150 Ohm
Load Impedance 600 Ohm minimum
Headphone Output: (at Maximum Volume; Into 100 Ohm load)
Frequency Response 22Hz to 22kHz (+/-0.1dB
Power into Ohms 90 mW into 100 Ohms
THD+N <0.06% (-66dB)
Signal-to-Noise Ratio -90dB, A-weighted
Max Output Level into 100 Ohms +2.0dBV, typical
Output Impedance 75 Ohm
Load Impedance 32 to 600 Ohms

In The Box

  • ICON iKeyboard 6X 61-Keys Semi Weighted Keys Keyboard
  • USB Cable
