PreSonus Studio 1824c 18×20 USB-C Audio/MIDI Interface

PRESONUS
Availability:

In stock


Offering ultrahigh-resolution conversion, eight Class-A preamps, a host of outputs, and a powerful software package for bands and engineers in project studios, the PreSonus Studio 1824c rackmount 18×20 USB audio/MIDI interface blends studio-quality, sonic performance, bountiful and expandable I/O, and refreshing ease of use, all in a sturdy chassis that occupies just a single rack space.

Key Features

  • Bands and Project Studios
  • USB Type-C and USB Type-A Connectivity
  • 8 Class-A Mic/Line Preamps (2 with Hi-Z)
  • 2 Headphone Outs, 10 DC-Coupled Line Out
  • 24-Bit / 192 kHz AD/DA
  • External Power Supply / Mac, Windows
  • Phantom Power, Monitor Mute/Mono
  • MIDI, S/PDIF, and ADAT I/O
  • 4-Segment I/O Metering, Wordclock Out
  • DAWs, VIs, Plug-Ins, Loops, and Samples

 195,000

In stock

PreSonus Studio 1824c USB Type-C Audio Interface

Offering ultrahigh-resolution conversion, eight Class-A preamps, a host of outputs, and a powerful software package for bands and engineers in project studios, the PreSonus Studio 1824c rackmount 18×20 USB audio/MIDI interface blends studio-quality, sonic performance, bountiful and expandable I/O, and refreshing ease of use, all in a sturdy chassis that occupies just a single rack space.

XMAX Class-A Preamps

The Studio 1824c’s four XMAX Class-A mic preamps use discrete components and are known for their high headroom, musicality, and transparency with ultralow noise. With switchable 48V phantom power, XLR-1/4″ combo inputs, and a line/instrument switch (for inputs 1-2)

High-Resolution AD/DA Converters

Boasting support for digital resolutions up to 24-bit / 192 kHz, the Studio 1824c Usb Audio Interface is equipped to perform AD/DA conversion with clarity and precision. It can also serve as a quality DAC for playback of ultrahigh-resolution files from your computer.

Multiple Headphone and Monitor Outputs

Dedicated buttons are presented for muting the main monitor feed and summing it to mono; both are valuable functions for running efficient sessions. Easy-to-use DSP monitor mixing lets you create four discrete, near-zero-latency mixes, enough for large ensembles.

DC-Coupled Outputs

All 10 analog outputs (two main and eight additional line outs) on the Studio 1824c are DC-coupled, allowing them to send MIDI sync and sequencer data from your DAW as CV (control voltage) to external analog synthesizers and drum modules. This makes the Studio 1824c well suited for marrying analog sequencers, synths, and Eurorack gear with your DAW.

MIDI I/O

Integration of MIDI equipment is no problem for the Studio 1824c. It offers traditional 5-pin MIDI I/O for straightforward connectivity with common gear such as a MIDI keyboard controller, synthesizer, or drum machine.

ADAT Optical I/O

With eight channels of ADAT optical input (four channels at 96 kHz), you can expand the Studio 1824c with an 8-channel mic preamp with ADAT conversion, such as the DigiMax DP88 (available separately).

S/PDIF Digital I/O

The RCA coaxial jacks are a welcome bonus for interconnecting digital audio equipment outfitted with S/PDIF digital I/O. DJ mixers, outboard mic preamps, and external converters can often be found with S/PDIF input and output ports.

Studio One Artist Software

  • Single-window work environment
  • Powerful drag-and-drop functionality
  • Unlimited audio tracks, MIDI tracks, virtual instruments, buses, and FX channels
  • Content browser with convenient sort options and preview player
  • Intuitive MIDI-mapping system
  • Real-time audio time-stretching and resampling
  • Multitrack comping and MIDI editing
  • Transient detection and editing, plus groove extraction
  • Automatic delay compensation
  • Advanced automation
  • Integrates tightly with Celemony Melodyne
  • Instantly configures to PreSonus interfaces
  • Compatible with ASIO, Windows Audio, and Core Audio compliant interfaces
  • 26 native effects (32-bit effects) and virtual instrument plug-ins
  • Over 10GB of third-party software, loops, and instruments
  • Mac and Windows compatible
Weight 6.91 lbs
Dimensions 24.5 × 9.4 × 0.3 in
Brands

PreSonus Studio 1824c Specs

Form Factor Rackmount
Display 10 x Multi-Segment LED Meter
Channels of I/O Analog:
8 Inputs / 10 Outputs at 192 kHz
Digital:
10 Inputs / 10 Outputs at 48 kHz
Max Sample Rate/Resolution 192 kHz / 24-Bit
Number of Mic Preamps 8
Input Level Adjustment 8 x Knob
Expansion Slots None
Pad None
Gain/Trim Range Mic Inputs:
80 dB
Line Inputs:
40 dB
Hi-Z Inputs:
80 dB
High-Pass Filter None
Solo/Mute Mute per Master
Connectivity
Analog Audio I/O 2 x Combo XLR-1/4″ TRS Balanced/Unbalanced Mic/Line/Hi-Z Input (Front Panel)
6 x Combo XLR-1/4″ TRS Balanced Mic/Line Input
2 x 1/4″ TRS Balanced Monitor Output (DC-Coupled)
8 x 1/4″ TRS Balanced Line Output (DC-Coupled)
2 x 1/4″ TRS Unbalanced Headphone Output
Phantom Power 48 V, Selectable On/Off (Applied to All Inputs)
Phantom Power Current > 10 mA per Channel
Digital Audio I/O 1 x TOSLINK Optical ADAT Input (S/MUX Support)
1 x TOSLINK Optical ADAT Output (S/MUX Support)
1 x RCA Coaxial S/PDIF Input
1 x RCA Coaxial S/PDIF Output
Host Connection / USB 1 x USB Type-C (Class-Compliant USB 2.0)
USB (Non-Host) None
Sync I/O 1 x BNC Word Clock Output
Network I/O None
MIDI I/O 1 x DIN 5-Pin Input
1 x DIN 5-Pin Output
Wireless Connectivity None
Performance
Frequency Response Mic, Line Inputs:
20 Hz to 20 kHz (Unity Gain)
Hi-Z Inputs:
20 Hz to 20 kHz (Min Gain)
Monitor Outputs:
20 Hz to 20 kHz (Unity Gain)
Line Outputs:
20 Hz to 20 kHz
Headphone Outputs:
20 Hz to 20 kHz (Unity Gain)
Max Input Level Mic Inputs:
+16 dBu (Balanced, Min Gain)
Line Inputs:
+21 dBu (Balanced, Min Gain)
Hi-Z Inputs:
+15 dBu (Unbalanced, Min Gain)
Max Output Level Line/Monitor Outputs:
+18 dBu (Balanced)
Headphone Output Power 150 mW per Channel into 60 Ohms (Max)
Impedance Mic Inputs:
1.4 Kilohms
Line Inputs:
10 Kilohms
Hi-Z Inputs:
1 Megohm
Headphone Outputs:
32 to 600 Ohms
Dynamic Range AD/DA Converters:
114 dB
Mic Inputs:
110 dBA (Min Gain)
Line/Hi-Z Inputs:
112 dBA (Min Gain)
Monitor Outputs:
108 dBA
Line Outputs:
108 dBA
Headphone Outputs:
103 dBA (1 kHz)
THD+N Mic Inputs:
0.005% (1 kHz, Unity Gain)
Line Inputs:
0.005% (1 kHz, Min Gain)
Hi-Z Inputs:
0.02% (1 kHz, Min Gain)
Monitor Outputs:
0.004% (1 kHz, Unity Gain, at -1 dBFS)
Line Outputs:
0.004% (1 kHz, Unity Gain, at -1 dBFS)
Headphone Outputs:
0.25% (1 kHz, Unity Gain)
EIN Mic Inputs:
-128 dBu A-Weighted (150-Ohm Source, Max Gain)
Digital Audio
Sample Rates Up to 192 kHz (AD/DA Conversion)
Sample Rate Conversion None
Bit Depths Up to 24-Bit (AD/DA Conversion)
Sync Sources ADAT, Internal, S/PDIF
Memory Card Slot None
Compatibility
OS Compatibility macOS 10.13 or Later (64-Bit, Only)
Windows 10 (64-Bit, Only)
iOS 10 or Later
Android 6 or Later
Included Software Studio One Artist
Ableton Live Lite
Compatible Software (Not Included) Any Core Audio (Mac) Compliant Software
Supported Drivers/API & Plug-Ins macOS Class-Compliant (No Driver Needed)
Windows Driver Downloadable from Manufacturer
Processor Requirement Mac:
Intel Core i3
PC:
Intel Core i3
AMD
RAM Requirements 4 GB, 8 GB Recommended
Storage Requirements 32 GB
Minimum Display Resolution 1366 x 768
Mobile Device Compatibility iPad Pro
iPad Air
iPad Air 2
iPad Mini with Retina
iPad Mini 4
iPad 4th Gen.
Android Smartphone
Android Tablet
Required Hardware USB Cable (Included)
Available USB 2.0 Port or USB Type-C Port
Internet Connection Required for Registration, Software/Driver Download
Power
Power Requirements AC/DC Power Adapter (Included)
Rail Voltage Preamp:
+30 V
AC/DC Power Adapter 12 V, Center-Positive (Included)
Physical
Rackmount Size 1 RU (with Included Hardware)
Dimensions 19 x 5.5 x 1.75″ / 482.6 x 139.7 x 44.45 mm
Weight 4.8 lb / 2.2 kg
Packaging Info
Package Weight 6.91 lb
Box Dimensions (LxWxH) 24.5 x 9.4 x 0.3″



In The Box

  • PreSonus Studio 1824c Rackmount 18×20 USB Type-C Audio/MIDI Interface
  • Studio One Artist Software (Download)
  • Studio Magic Plug-In Suite (Download)
  • USB Type-C Cable (3.3′)
  • USB Type-A to USB Type-C Cable (3.3′)
  • External Power Supply
  • Limited 1-Year Warranty
