JBL 308P MkII Powered 8 Two-Way Studio Monitor
JBL 308P MkII
JBL 308P MkII Powered 8 Two-Way Studio Monitor
JBL 308P MkII
, ,

JBL 308P MkII Powered 8″ Two-Way Studio Monitor (Single)

JBL
Availability:

In stock
Audio engineers, producers, and musicians looking for a high-quality monitoring solution will be impressed with the  JBL 308P MkII – Powered 8″ Two-Way Studio Monitor, a bi-amplified reference monitor with next-generation drivers, offering high detail, precise imaging, a wide sweet spot, and a remarkable dynamic range to enhance the mix capabilities of any modern workspace

Key Features

  • Bi-Amplified Powered Reference Monitor
  • Dual 56W Class-D Amplifiers
  • Low Frequency Woofer: 8″
  • Neodymium Woven-Composite Tweeter: 1″
  • Image Control Waveguide Technology
  • Balanced XLR and 1/4″ TRS Inputs
  • 3-Position HF Trim Switch
  • Boundary EQ for Placement Near Walls
  • Slip Stream Low-Frequency Port Design
  • Selectable Input Sensitivity Switch

₨ 122,500

In stock

Order On Whatsapp

Audio engineers, producers, and musicians looking for a high-quality monitoring solution will be impressed with the  JBL 308P MkII – Powered 8″ Two-Way Studio Monitor, a bi-amplified reference monitor with next-generation drivers, offering high detail, precise imaging, a wide sweet spot, and a remarkable dynamic range to enhance the mix capabilities of any modern workspace. The magnetically-shielded 308P MkII features dual 56W Class-D amplifiers, which power the 8″ low frequency woofer and woven-composite 1″ neodymium tweeter. The combined output of the woofer and tweeter offer a frequency response of 45 Hz to 20 kHz with a peak SPL of 112 dB.

The monitor features JBL’s Image Control Waveguide technology for accurate audio reproduction and JBL’s Slip Stream port design for improved bass response. The 308P MkII is equipped with a boundary EQ for controlling the low frequency response when placed near a wall, as well as a 3-position HF trim switch. To ensure flexible connectivity, JBL included a balanced XLR input and a balanced 1/4″ TRS input, both of which feature dented level control. Other features include a selectable input sensitivity switch that ensures compatibility with a range of signal sources. The JBL 308P MkII ships with a power cord.

  • Patented Image Control Waveguide for detailed imaging and a broad, room-friendly sweet spot
  • High-quality JBL transducers for optimized transient response and improved linearity
  • Patented Slip Stream low-frequency port for superior bass performance at all playback levels
  • Dual integrated, custom Class-D amplifiers provide 112W of power for high output and dynamic range
  • Boundary EQ settings compensate for low-frequency variants introduced by the environment
  • HF Trim switch adjusts high-frequency output to room acoustics or personal preferences
  • Flexible connectivity with balanced XLR and 1/4″ TRS inputs, +4 dBu / -10 dBV input-sensitivity switch and adjustable volume control
  • Engineered to JBL Linear Spatial Reference design criteria for outstanding accuracy in any working space
  • Strenuous JBL 100-hour full-power test ensures years of reliability
  • Sleek, modern design provides a visual upgrade to any studio

SKU: 308P MKII Categories: , , Tags: , , , , , , , ,
Weight 21.68 lbs
Dimensions 19 × 13 × 13 in
Brands

JBL 308P MKII Specs

Studio Monitor
Monitor Type Active 2-Way
Enclosure Bass-Reflex, Shielded
Power Rating 112 W
Drivers HF Driver: 1 x 1″ / 25.4 mm Dome Tweeter
LF Driver: 1 x 8″ / 203.2 mm Woofer
Amplification 1 x HF Amplifier: Class-D Rated at 56 W
1 x LF Amplifier: Class-D Rated at 56 W
Performance
Frequency Range 37 Hz to 24 kHz (at -10 dB)
Frequency Response 45 Hz to 20 kHz ± 3 dB
Maximum Sound Pressure Level (SPL) 112 dB
Signal-to-Noise Ratio 75 dBA
Total Harmonic Distortion (THD) <10%
THD+N < 0.2%
Maximum Input Level +20.3 dBu (Balanced)
+6 dBV (Unbalanced)
Protections and Limiting Peak Limiter
Signal Processing
EQ HF Shelf
LF Shelf
Crossover
Crossover Frequency 1800 Hz, 24 dB/Octave Slope
Crossover Type Linkwitz-Riley
Connectivity
Audio I/O 1 x XLR Balanced Female Analog Input
1 x 1/4″ TRS Balanced Female Analog Input
Power
AC Input Power 100 to 240 VAC, 50/60 Hz
General
Enclosure Material ABS, MDF
Dimensions (W x H x D) 10 x 16.5 x 12.1″ / 254 x 419.1 x 307.3 mm
Weight 17.9 lb / 8.1 kg
Packaging Info
Package Weight 21.68 lb
Box Dimensions (LxWxH) 19 x 13 x 13″

In The Box

  • JBL 308P MkII Powered 8″ Two-Way Studio Monitor
  • Power Cord
